Automotive Front Bumper Body Injection Mold

The Automotive Front Bumper Body Injection Mold is a core piece of equipment for automotive exterior parts, used to produce front protection components for vehicles. It has evolved from metal stamping parts to lightweight plastic parts. SIKAIDA molds integrate advanced design and manufacturing capabilities, with strict quality control throughout the entire factory process, ensuring stable and durable products.

Product Details

1. Product Structure and Function

This Automotive Front Bumper Body Injection Mold is used to produce front bumper covers. The plastic bumper consists of an outer panel, cushioning material, and a steel crossbeam. It is available in two parting line types: external parting (visible parting line) and internal parting (hidden parting line, suitable for mid-to-high-end vehicles). Core functions include collision protection, component installation, ventilation, decoration, and pedestrian protection.

2. Material Application

The bumper uses a PP+EPDM+TD20 system, with PP as the base material, EPDM enhancing elasticity, and TD20 reinforcing rigidity. The materials are lightweight, impact-resistant, weather-resistant, easy to process, cost-effective, and recyclable, meeting production and environmental protection requirements.

3. Product Specifications and Precision

The typical dimensions of the Automotive Front Bumper Body Injection Mold are approximately 2000mm × 800mm × 700mm, with an average wall thickness of 3.0mm and a weight of 4-5 kg. Dimensional accuracy is ±0.05mm, surface finish Ra≤0.4μm, assembly clearance 0.5-1mm, and internal parting line height difference ≤0.05mm.

Product Features and Applications

1. Mold Structure Features

The Automotive Front Bumper Body Injection Mold adopts an integrated moving and stationary mold design. The mold base is made of QT500 material, and the cavity/core is made of P20 or 718 steel. The parting surface is optimized, and the internal parting line can be hidden. Equipped with a multi-point hot runner gating system, a combined cooling system, an ejector block system, and a stable core-pulling mechanism, it balances performance and ease of processing.

2. Application Advantages

The Automotive Front Bumper Body Injection Mold conforms to GB17354-1998 standards, protecting vehicles in low-speed collisions; it is over 40% lighter than metal bumpers, improving fuel economy; it offers high design freedom, strong functional integration, excellent weather resistance, and a long service life.

3. Typical Applications

Widely used in various passenger vehicles: economy cars prioritize cost, using external parting lines and PP+EPDM+T15 materials; mid-to-high-end cars prioritize aesthetics, using internal parting lines and PP+EPDM+TD20 materials; new energy vehicles prioritize lightweighting and intelligent features; SUVs and MPVs prioritize aerodynamics and off-road capability.

Manufacturing Process

1. Mold Design

Through product structure analysis and MOLDFLOW mold flow simulation optimization, detailed design of core mechanisms such as parting lines, gating, and cooling is performed to ensure scientific design.

2. Mold Manufacturing

QT500 mold base and P20/718H cavity/core materials are used. Precision machining, nitriding heat treatment, and mirror polishing ensure mold quality.

3. Injection Molding

Materials are dried at 80-100℃ for 2-4 hours, then injection molded according to specifications (molding cycle 10-15 seconds). After molding, gate removal, inspection, and packaging are performed, with surface treatment as necessary.

4. Quality Control

Full-process quality control ensures product appearance is defect-free, dimensions conform to drawings, and performance meets standards, passing multiple performance tests.

Development Trends:

1. Materials Technology

Automotive front bumper body injection mold materials are developing towards lightweight (composite materials), high performance, environmental friendliness (recyclable), and intelligence (smart materials) to support intelligent driving.

2. Mold Technology

The widespread adoption of internal parting lines, multi-point hot runners, and conformal cooling technologies improves mold automation and intelligence, shortening cycles and increasing efficiency.

3. Industry Trends

Industry demand is increasing, industry concentration is rising, digital transformation is deepening, and technology is extending into fields such as robotics.
